Welcome to Mahesh Engineering Services

E-mail Print PDF

:: Welcome to Mahesh Engineering Services ::

Mahesh Engineering Services on Biteable.

Welcome, The City’s Largest ONE STOP SHOP for Electricals and Industrial Power Control.

Mahesh Engineering Services, A Universe of 1000+ Product Lines from 30+ OE Companies, Awaits you at the largest Industrial House in Power and Control Electrical Business. Choose from 83 Group Products, 125 Sections, 300 Categories of Entire World of Switchgear, Control gear, About 45 Types of Wires, Cables Designs, 60 Divisions of Panel Board and Control Technology Accessories. Meeting Engineering and Global Standards across the entire T&D value chain from HT to LT to Most Composite yet intricate Distributions in Power and Control Automation.

While entering into the Seventeenth year of our establishment, we approach your goodselves to kindly register our name in your "Vendor's List" for any and every requirement in Electrical Switchgear & Industrial Components etc. The details of items we deal in are given in the subsequent sections. You will note that we deal in a vast range of products, and beyond products, services and solution oriented business.

Thanks to our vast product range and our excellent service, we are one of the fastest growing companies in this industry, with a reputation second to none. It is this goodwill and record of excellence in service we place at your disposal. While, Many of our customer feels We are Growing to Serve, At Mahesh Engineering Services, We strongly feel we are Serving to Grow.

We are confident that a trial order would win your future custom, and we should be grateful for an opportunity to prove the truth of our claim. We think you will find our prices are the best possible, commensurate with the high quality of our goods. Any orders, which you entrust, will receive our most careful attention. Looking forward to build a healthy business relationship.

| About us | Our Vision | Our History | Our Activities | Our Principals |

| Authorization Certificates | Our Esteemed Customers |


Last Updated on Friday, 21 April 2017 14:38


Type 2 Co-Ordination Chart

E-mail Print PDF




DOWNLOAD HERE

Last Updated on Friday, 07 July 2017 12:43


Setting of MCCB for Motor Circuit

E-mail Print PDF


For Short Circuit Protection (Magnetic Setting):

Example for Setting of MCCB  for Motor Circuit

  •  When we select an MCCB for motor application, it is necessary that the instantaneous release setting in the MCCB is set to a value higher than the highest anticipated Motor magnetizing inrush current during switching-on the motor.
  • The values for magnetizing inrush current (sub transient current) are higher in case of high efficiency motors as compared to standard efficiency motors.
  • By theoretical and empirical means it is established that the maximum ratio between peak and LRC can go up to 2.5 for high efficiency motors.

Motor Starting Current:

  • Motor starting current is one of the most important electrical parameter of motor to understand its electrical characteristics.
  • It is important to note the distinction between inrush current and starting current
  • The current drawn by the motor in different phases are.
  1. Inrush Current (Sub transient phase)
  2. Starting or Lock Rotor Current (Transient phase)
  3. Steady state operation.

Inrush Current (Sub transient phase)

  • During the initial phase of motor starting Current drawn by motor is known as inrush current or peak current.
  • Inrush current is the current drawn between switch on and when the magnetic fields are established in the motor this current is due to magnetizing inrush component of the motor starting current.
  • Inrush Current: It is generally 13 to 17 x FLA for older motors to New Motor.
  • The duration of inrush current: It is in milliseconds.
  • Motor circuits are highly inductive. Motor can be started at any point on voltage wave of the circuit. Depending on the initiation of the circuit i.e. point on the voltage wave.
  • The magnitude of the
    asymmetry is directly related to X/R ratio of the circuit.

Starting Current (Transient phase)

  • Motor starting current or Lock Rotor Current is the current drawn while Motor is accelerating to full speed.
  • Starting Current: It is depend upon Starting method of Motor
  • For DOL Starter : 6 to 8 x FLA
  • Star- Delta: 2 to 3 x FLA
  • Auto Transformer: 2 to 3 x FLA
  • Soft Starter: 3 to 5 x FLA
  • VFD: 1.5 x FLA
  • The duration of Starting current: Depend upon Load and Application (10 To 40 Sec)

The magnetic settings for Motor should be as follows:

  •  Motor Starting Current < Magnetic Setting of MCCB < Short Circuit Current
  • The MCCB should not trip during starting of the motor. Therefore setting should be 1.3 times the starting current. Normally the starting current will be 6 times the full load current of the motor. Therefore it will be 7.8 times the full load current.
  • However you have to calculate the short circuit current at the motor terminal. This depends on source fault level at the bus feeding the motor and cable impedance between the MCCB and motor. The setting on the MCCB should be less than the calculated short circuit current.
  • Motor Acceleration Time < Magnetic Time Setting of MCCB
  • Another important consideration is the acceleration time should be less than the time set on the MCCB for the magnetic setting.
Last Updated on Tuesday, 04 July 2017 12:27


L&T Switchgear Training Centre - Training calendar for FY2017-18

E-mail Print PDF

L&T Switchgear Training Centre, Pune. conducts around 22 Training programs for electrical professionals,

with the objective of promoting good Electrical Engineering & Safety Practices.

These programs are continuously updated in line with current industrial trends & technology.

The contents of different programs & training calendar for  FY 2017–18 is here for download for your reference.

We at Mahesh Engineering Services, are sure, you will find these programs extremely useful for you and your organization,

We look forward for all your training needs in Electrical Engineering (customized programs shall be organized based on your request)

Pl. feel free to contact us for any clarifications.

Thanks & Regards,


Last Updated on Monday, 03 April 2017 07:32

  • «
